Step1: Product
STMicroelectronics ECMF02-3HSM6
Image shown is a representation only
Manufacturer
Manufacturer No
ECMF02-3HSM6
Package
6-UFDFN
Packaging
Tape & Reel (TR)
Description
CMC 100MA 2LN SMD ESD
Detailed Description
2 Line Common Mode Choke Surface Mount 100mA DCR 5Ohm (Typ)
Datasheet
Series
ECMF
Features
TVS Diode ESD Protection
Packaging
Tape & Reel (TR)
Filter Type
Signal Line
Height (Max)
0.022" (0.55mm)
Manufacturer
STMicroelectronics
Mounting Type
Surface Mount
Package / Case
6-UFDFN
Number of Lines
2
Size / Dimension
0.063" L x 0.053" W (1.60mm x 1.35mm)
Base Product Number
ECMF02
Current Rating (Max)
100mA
Operating Temperature
-40°C ~ 85°C
DC Resistance (DCR) (Max)
5Ohm (Typ)
| Attribute | Value |
|---|---|
| Series | ECMF |
| Features | TVS Diode ESD Protection |
| Packaging | Tape & Reel (TR) |
| Filter Type | Signal Line |
| Height (Max) | 0.022" (0.55mm) |
| Manufacturer | STMicroelectronics |
| Mounting Type | Surface Mount |
| Package / Case | 6-UFDFN |
| Number of Lines | 2 |
| Size / Dimension | 0.063" L x 0.053" W (1.60mm x 1.35mm) |
| Base Product Number | ECMF02 |
| Current Rating (Max) | 100mA |
| Operating Temperature | -40°C ~ 85°C |
| DC Resistance (DCR) (Max) | 5Ohm (Typ) |
