Step1: Product
Siemens 3SU11502BF601BA0
Image shown is a representation only
Manufacturer
Manufacturer No
3SU11502BF601BA0
Packaging
Bulk
Description
SWITCH SELECT 2POS SPST 10A 500V
Detailed Description
Selector Switch 2 Position SPST-NO 10A (AC/DC) 500 V Panel Mount
DataSheet
Type
Standard
Series
3SU1
Circuit
SPST-NO
Packaging
Bulk
Part Status
Active
Illumination
Non-Illuminated
Manufacturer
Siemens
Mounting Type
Panel Mount
Approval Agency
CCC, CE, CSA, EAC, UL
Electrical Life
10,000,000 Cycles
Mechanical Life
100,000 Cycles
Switch Function
Off-On
Termination Style
Screw Terminal
Ingress Protection
IP66/IP67/IP69K - Dust Tight, Water Resistant, Waterproof
Base Product Number
3SU1150
Depth Behind Flange
49.70mm
Number of Positions
2
Voltage Rating - AC
500 V
Voltage Rating - DC
500 V
Current Rating (Amps)
10A (AC/DC)
Operating Temperature
-25°C ~ 70°C
Panel Cutout Dimensions
Circular - 22.30mm Dia
| Attribute | Value |
|---|---|
| Type | Standard |
| Series | 3SU1 |
| Circuit | SPST-NO |
| Packaging | Bulk |
| Part Status | Active |
| Illumination | Non-Illuminated |
| Manufacturer | Siemens |
| Mounting Type | Panel Mount |
| Approval Agency | CCC, CE, CSA, EAC, UL |
| Electrical Life | 10,000,000 Cycles |
| Mechanical Life | 100,000 Cycles |
| Switch Function | Off-On |
| Termination Style | Screw Terminal |
| Ingress Protection | IP66/IP67/IP69K - Dust Tight, Water Resistant, Waterproof |
| Base Product Number | 3SU1150 |
| Depth Behind Flange | 49.70mm |
| Number of Positions | 2 |
| Voltage Rating - AC | 500 V |
| Voltage Rating - DC | 500 V |
| Current Rating (Amps) | 10A (AC/DC) |
| Operating Temperature | -25°C ~ 70°C |
| Panel Cutout Dimensions | Circular - 22.30mm Dia |
