Step1: Product
Sensata - Gigavac Industrial GH1-115VDC
Image shown is a representation only
Manufacturer
Manufacturer No
GH1-115VDC
Packaging
Box
Description
3.5KV SPDT HV RELAY
Detailed Description
Contactor SPDT (1 Form C) 25 A 115VDC Coil Panel Mount
DataSheet
Series
GH1
Features
Sealed - Hermetically
Packaging
Box
Coil Power
2.2W
Part Status
Active
Coil Current
19.2 mA
Coil Voltage
115VDC
Contact Form
SPDT (1 Form C)
Manufacturer
Sensata - Gigavac Industrial
Operate Time
6 ms
Release Time
6 ms
Mounting Type
Panel Mount
Coil Resistance
6kOhms
Contact Material
Copper
Switching Voltage
3500VAC, 3500VDC - Max
Termination Style
Solder Cup, Solder Turret
Must Operate Voltage
80 VDC
Must Release Voltage
5 VDC
Operating Temperature
-55°C ~ 125°C
Contact Rating (Current)
25 A
| Attribute | Value |
|---|---|
| Series | GH1 |
| Features | Sealed - Hermetically |
| Packaging | Box |
| Coil Power | 2.2W |
| Part Status | Active |
| Coil Current | 19.2 mA |
| Coil Voltage | 115VDC |
| Contact Form | SPDT (1 Form C) |
| Manufacturer | Sensata - Gigavac Industrial |
| Operate Time | 6 ms |
| Release Time | 6 ms |
| Mounting Type | Panel Mount |
| Coil Resistance | 6kOhms |
| Contact Material | Copper |
| Switching Voltage | 3500VAC, 3500VDC - Max |
| Termination Style | Solder Cup, Solder Turret |
| Must Operate Voltage | 80 VDC |
| Must Release Voltage | 5 VDC |
| Operating Temperature | -55°C ~ 125°C |
| Contact Rating (Current) | 25 A |
