Step1: Product
Semtech Corporation TS55101-QFNR
Image shown is a representation only
Manufacturer
Manufacturer No
TS55101-QFNR
Package
16-VFQFN Exposed Pad
Packaging
Tray
Description
IC BATT CHG LI-ION 16PQFN
Detailed Description
Charger IC Lithium Ion 16-QFN (3x3)
DataSheet
Interface
I2C
Packaging
Tray
Part Status
Obsolete
Manufacturer
Semtech Corporation
Mounting Type
Surface Mount
Package / Case
16-VFQFN Exposed Pad
Fault Protection
Over Current, Over Temperature, Over Voltage
Battery Chemistry
Lithium Ion
Current - Charging
Constant
Base Product Number
TS55101
Battery Pack Voltage
4.2V
Charge Current - Max
2A
Operating Temperature
-40°C ~ 85°C (TA)
Programmable Features
Voltage
Voltage - Supply (Max)
16.5V
Supplier Device Package
16-QFN (3x3)
| Attribute | Value |
|---|---|
| Interface | I2C |
| Packaging | Tray |
| Part Status | Obsolete |
| Manufacturer | Semtech Corporation |
| Mounting Type | Surface Mount |
| Package / Case | 16-VFQFN Exposed Pad |
| Fault Protection | Over Current, Over Temperature, Over Voltage |
| Battery Chemistry | Lithium Ion |
| Current - Charging | Constant |
| Base Product Number | TS55101 |
| Battery Pack Voltage | 4.2V |
| Charge Current - Max | 2A |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Programmable Features | Voltage |
| Voltage - Supply (Max) | 16.5V |
| Supplier Device Package | 16-QFN (3x3) |
