Semtech Corporation LR1120IMLTRT
Image shown is a representation only
Manufacturer
Manufacturer No
LR1120IMLTRT
Package
32-VFQFN Exposed Pad
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
RF TXRX MOD NAVIGATION WIFISMD
Detailed Description
Navigation, WiFi 802.11b/g/n, BeiDou, GNSS, GPS, LoRa™ Transceiver Module 869MHz, 915MHz, 1.57542GHz, 2.45GHz Antenna Not Included Surface Mount
DataSheet
Mfr
Semtech Corporation
Protocol
802.11b/g/n, BeiDou, GNSS, GPS, LoRa™
Data Rate
43.3Mbps
Frequency
869MHz, 915MHz, 1.57542GHz, 2.45GHz
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Modulation
16-QAM, BPSK, DBPSK, DQPSK, DSSS, FHSS, FSK, GFSK, GMSK, OFDM, QPSK
Part Status
Active
Sensitivity
-144dBm
Antenna Type
Antenna Not Included
Mounting Type
Surface Mount
Package / Case
32-VFQFN Exposed Pad
Power - Output
22dBm
Voltage - Supply
1.8V ~ 3.7V
Serial Interfaces
SPI
RF Family/Standard
Navigation, WiFi
Current - Receiving
5.4mA ~ 8.3mA
DigiKey Programmable
Not Verified
Operating Temperature
-55°C ~ 125°C
Current - Transmitting
18.5mA ~ 118mA
| Attribute | Value |
|---|---|
| Mfr | Semtech Corporation |
| Protocol | 802.11b/g/n, BeiDou, GNSS, GPS, LoRa™ |
| Data Rate | 43.3Mbps |
| Frequency | 869MHz, 915MHz, 1.57542GHz, 2.45GHz |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Modulation | 16-QAM, BPSK, DBPSK, DQPSK, DSSS, FHSS, FSK, GFSK, GMSK, OFDM, QPSK |
| Part Status | Active |
| Sensitivity | -144dBm |
| Antenna Type | Antenna Not Included |
| Mounting Type | Surface Mount |
| Package / Case | 32-VFQFN Exposed Pad |
| Power - Output | 22dBm |
| Voltage - Supply | 1.8V ~ 3.7V |
| Serial Interfaces | SPI |
| RF Family/Standard | Navigation, WiFi |
| Current - Receiving | 5.4mA ~ 8.3mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -55°C ~ 125°C |
| Current - Transmitting | 18.5mA ~ 118mA |
