Step1: Product
Raltron Electronics RSP-500.000-2805-NS1
Image shown is a representation only
Manufacturer
Manufacturer No
RSP-500.000-2805-NS1
Packaging
Tray
Description
28mm OD x 5mm Speaker
Detailed Description
8 Ohms General Purpose Speaker 500 mW 300 Hz ~ 6 kHz Top Round
DataSheet
Type
General Purpose
Shape
Round
Impedance
8 Ohms
Packaging
Tray
Technology
Magnetic
Part Status
Active
Power - Max
1 W
Termination
Wire Leads with Connector
Manufacturer
Raltron Electronics
Port Location
Top
Power - Rated
500 mW
Frequency Range
300 Hz ~ 6 kHz
Material - Cone
Metal
Efficiency - dBA
89.00
Size / Dimension
1.102" Dia (28.00mm)
Efficiency - Type
Sound Pressure Level (SPL)
Material - Magnet
Nd-Fe-B
Ingress Protection
IP67 - Dust Tight, Waterproof
Efficiency - Testing
100mW/100mm
Height - Seated (Max)
0.138" (3.50mm)
Operating Temperature
-20°C ~ 60°C
Frequency - Self Resonant
500Hz
| Attribute | Value |
|---|---|
| Type | General Purpose |
| Shape | Round |
| Impedance | 8 Ohms |
| Packaging | Tray |
| Technology | Magnetic |
| Part Status | Active |
| Power - Max | 1 W |
| Termination | Wire Leads with Connector |
| Manufacturer | Raltron Electronics |
| Port Location | Top |
| Power - Rated | 500 mW |
| Frequency Range | 300 Hz ~ 6 kHz |
| Material - Cone | Metal |
| Efficiency - dBA | 89.00 |
| Size / Dimension | 1.102" Dia (28.00mm) |
| Efficiency - Type | Sound Pressure Level (SPL) |
| Material - Magnet | Nd-Fe-B |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Efficiency - Testing | 100mW/100mm |
| Height - Seated (Max) | 0.138" (3.50mm) |
| Operating Temperature | -20°C ~ 60°C |
| Frequency - Self Resonant | 500Hz |
