Step1: Product
Powerex Inc. CN240610
Image shown is a representation only
Manufacturer
Manufacturer No
CN240610
Package
Module
Packaging
Bulk
Description
DIODE MODULE GP 600V 100A MODULE
Detailed Description
Diode Array 1 Pair Common Anode 600 V 100A (DC) Chassis Mount Module
DataSheet
Speed
Standard Recovery >500ns, > 200mA (Io)
Packaging
Bulk
Technology
Standard
Part Status
Obsolete
Manufacturer
Powerex Inc.
Mounting Type
Chassis Mount
Package / Case
Module
Diode Configuration
1 Pair Common Anode
Supplier Device Package
Module
Reverse Recovery Time (trr)
800 ns
Current - Reverse Leakage @ Vr
20 mA @ 600 V
Voltage - DC Reverse (Vr) (Max)
600 V
Voltage - Forward (Vf) (Max) @ If
1.5 V @ 100 A
Current - Average Rectified (Io) (per Diode)
100A (DC)
| Attribute | Value |
|---|---|
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Packaging | Bulk |
| Technology | Standard |
| Part Status | Obsolete |
| Manufacturer | Powerex Inc. |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Diode Configuration | 1 Pair Common Anode |
| Supplier Device Package | Module |
| Reverse Recovery Time (trr) | 800 ns |
| Current - Reverse Leakage @ Vr | 20 mA @ 600 V |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 100 A |
| Current - Average Rectified (Io) (per Diode) | 100A (DC) |
