Step1: Product
Phoenix Contact 3003800
Image shown is a representation only
Manufacturer
Manufacturer No
3003800
Packaging
Bulk
Description
CONN TERM BLK FEED THRU 14-26AWG
Detailed Description
Terminal Block Connector 4 Position Feed Through Gray 14-26 AWG
DataSheet
Type
Feed Through
Color
Gray
Series
CLIPLINE MZDB
Packaging
Bulk
Part Status
Obsolete
Current - UL
15 A
Manufacturer
Phoenix Contact
Voltage - UL
600V
Current - IEC
17.5 A
Voltage - IEC
800V
Number of Levels
1
Stripping Length
9mm
Terminal - Width
10.4mm
Termination Style
Push In, Spring
Number of Positions
4
Material - Insulation
Polyamide (PA), Nylon
Wire Gauge or Range - AWG
14-26 AWG
Wire Gauge or Range - mm²
0.14-2.5mm²
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Type | Feed Through |
| Color | Gray |
| Series | CLIPLINE MZDB |
| Packaging | Bulk |
| Part Status | Obsolete |
| Current - UL | 15 A |
| Manufacturer | Phoenix Contact |
| Voltage - UL | 600V |
| Current - IEC | 17.5 A |
| Voltage - IEC | 800V |
| Number of Levels | 1 |
| Stripping Length | 9mm |
| Terminal - Width | 10.4mm |
| Termination Style | Push In, Spring |
| Number of Positions | 4 |
| Material - Insulation | Polyamide (PA), Nylon |
| Wire Gauge or Range - AWG | 14-26 AWG |
| Wire Gauge or Range - mm² | 0.14-2.5mm² |
| Material Flammability Rating | UL94 V-0 |
