Step1: Product
Phoenix Contact 2814634
Image shown is a representation only
Manufacturer
Manufacturer No
2814634
Package
Module
Packaging
Bulk
Description
CURRENT SENSOR HE/OL 11A
Detailed Description
Current Sensor 11A 1 Channel Hall Effect, Open Loop Bidirectional Module
DataSheet
Mfr
Phoenix Contact
Output
Ratiometric, Voltage and Current
Accuracy
±0.5%
Frequency
15Hz ~ 400Hz
Packaging
Bulk
Part Status
Obsolete
Sensor Type
Hall Effect, Open Loop
Polarization
Bidirectional
For Measuring
AC/DC
Mounting Type
DIN Rail
Response Time
330ms (AC), 40ms (DC)
Package / Case
Module
Voltage - Supply
20V ~ 30V
Current - Sensing
11A
Number of Channels
1
Operating Temperature
-20°C ~ 60°C
Current - Supply (Max)
40mA
| Attribute | Value |
|---|---|
| Mfr | Phoenix Contact |
| Output | Ratiometric, Voltage and Current |
| Accuracy | ±0.5% |
| Frequency | 15Hz ~ 400Hz |
| Packaging | Bulk |
| Part Status | Obsolete |
| Sensor Type | Hall Effect, Open Loop |
| Polarization | Bidirectional |
| For Measuring | AC/DC |
| Mounting Type | DIN Rail |
| Response Time | 330ms (AC), 40ms (DC) |
| Package / Case | Module |
| Voltage - Supply | 20V ~ 30V |
| Current - Sensing | 11A |
| Number of Channels | 1 |
| Operating Temperature | -20°C ~ 60°C |
| Current - Supply (Max) | 40mA |
