Step1: Product
Phoenix Contact 1778586
Image shown is a representation only
Manufacturer
Manufacturer No
1778586
Packaging
Tape & Reel (TR); Cut Tape (CT)
Description
TERM BLOCK HDR 5POS 2.50MM
Detailed Description
5 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.098" (2.50mm) Vertical Through Hole
DataSheet
Type
Header, Male Pins, Shrouded (4 Side)
Color
Black
Pitch
0.098" (2.50mm)
Series
COMBICON PTSM
Features
Pick and Place Cap
Packaging
Tape & Reel (TR); Cut Tape (CT)
Part Status
Active
Manufacturer
Phoenix Contact
Current - IEC
6A
Mounting Type
Through Hole
Voltage - IEC
160 V
Housing Material
Liquid Crystal Polymer (LCP)
Number of Levels
1
Insulation Height
0.295" (7.50mm)
Termination Style
Solder
Header Orientation
Vertical
Contact Tail Length
0.083" (2.10mm)
Number of Positions
5
Positions Per Level
5
Contact Mating Finish
Tin
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Type | Header, Male Pins, Shrouded (4 Side) |
| Color | Black |
| Pitch | 0.098" (2.50mm) |
| Series | COMBICON PTSM |
| Features | Pick and Place Cap |
| Packaging | Tape & Reel (TR); Cut Tape (CT) |
| Part Status | Active |
| Manufacturer | Phoenix Contact |
| Current - IEC | 6A |
| Mounting Type | Through Hole |
| Voltage - IEC | 160 V |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Number of Levels | 1 |
| Insulation Height | 0.295" (7.50mm) |
| Termination Style | Solder |
| Header Orientation | Vertical |
| Contact Tail Length | 0.083" (2.10mm) |
| Number of Positions | 5 |
| Positions Per Level | 5 |
| Contact Mating Finish | Tin |
| Material Flammability Rating | UL94 V-0 |
