Performance Motion Devices, Inc. MC54113
Image shown is a representation only
Manufacturer
Manufacturer No
MC54113
Package
100-LQFP
Packaging
Tray
Description
MAGELLAN STEP CTRL IC 1AXIS v1.2
Detailed Description
Bipolar Motor Driver CMOS CAN, RS-232, RS-485, SPI 100-TQFP (14x14)
DataSheet
Series
Magellan®
Function
Controller - Commutation, Current Management, Direction Management
Interface
CAN, RS-232, RS-485, SPI
Packaging
Tray
Technology
CMOS
Part Status
Active
Applications
DC Motor Controller, Brushless (BLDC), 2-Phase, General Purpose, Stepper Motor Controller
Manufacturer
Performance Motion Devices, Inc.
Mounting Type
Surface Mount
Package / Case
100-LQFP
Step Resolution
1 ~ 1/256
Current - Output
4mA
Voltage - Supply
2.97V ~ 3.63V
Motor Type - Stepper
Bipolar
Output Configuration
High Side, Low Side, Step/Direction
Operating Temperature
-40°C ~ 85°C (TA)
Supplier Device Package
100-TQFP (14x14)
| Attribute | Value |
|---|---|
| Series | Magellan® |
| Function | Controller - Commutation, Current Management, Direction Management |
| Interface | CAN, RS-232, RS-485, SPI |
| Packaging | Tray |
| Technology | CMOS |
| Part Status | Active |
| Applications | DC Motor Controller, Brushless (BLDC), 2-Phase, General Purpose, Stepper Motor Controller |
| Manufacturer | Performance Motion Devices, Inc. |
| Mounting Type | Surface Mount |
| Package / Case | 100-LQFP |
| Step Resolution | 1 ~ 1/256 |
| Current - Output | 4mA |
| Voltage - Supply | 2.97V ~ 3.63V |
| Motor Type - Stepper | Bipolar |
| Output Configuration | High Side, Low Side, Step/Direction |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Supplier Device Package | 100-TQFP (14x14) |
