Step1: Product
Pasternack PE51212
Image shown is a representation only
Manufacturer
Manufacturer No
PE51212
Packaging
Bag
Description
5DBIC MULTIBAND 824-2170MHZ UMCX
Detailed Description
RF ANTENNA GPS, GNSS Ceramic Patch U.FL (UMCX), I-PEX (2)
DataSheet
Gain
2dBi, 5dBi, 3dBi
VSWR
2, 2.5
Features
Cable - 100mm
Packaging
Bag
Part Status
Active
Termination
U.FL (UMCX), I-PEX (2)
Antenna Type
Ceramic Patch
Applications
GPS, GNSS
Height (Max)
0.039" (1.00mm)
Manufacturer
Pasternack
Frequency Group
Wide Band
Frequency Range
824MHz ~ 960MHz, 1.575GHz ~ 1.602GHz, 1.71GHz ~ 2.2GHz
Number of Bands
3
RF Family/Standard
Cellular, Navigation
Frequency (Center/Band)
892MHz, 1.588GHz, 1.955GHz
| Attribute | Value |
|---|---|
| Gain | 2dBi, 5dBi, 3dBi |
| VSWR | 2, 2.5 |
| Features | Cable - 100mm |
| Packaging | Bag |
| Part Status | Active |
| Termination | U.FL (UMCX), I-PEX (2) |
| Antenna Type | Ceramic Patch |
| Applications | GPS, GNSS |
| Height (Max) | 0.039" (1.00mm) |
| Manufacturer | Pasternack |
| Frequency Group | Wide Band |
| Frequency Range | 824MHz ~ 960MHz, 1.575GHz ~ 1.602GHz, 1.71GHz ~ 2.2GHz |
| Number of Bands | 3 |
| RF Family/Standard | Cellular, Navigation |
| Frequency (Center/Band) | 892MHz, 1.588GHz, 1.955GHz |
