Panjit International Inc. BAT721C_R1_00001
Image shown is a representation only
Manufacturer
Manufacturer No
BAT721C_R1_00001
Package
TO-236-3, SC-59, SOT-23-3
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
DIODE ARR SCHOTT 40V 200MA SOT23
Detailed Description
Diode Array 1 Pair Common Cathode 40 V 200mA (DC) Surface Mount TO-236-3, SC-59, SOT-23-3
DataSheet
Speed
Small Signal =< 200mA (Io), Any Speed
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
Schottky
Part Status
Active
Manufacturer
Panjit International Inc.
Mounting Type
Surface Mount
Package / Case
TO-236-3, SC-59, SOT-23-3
Base Product Number
BAT721
Diode Configuration
1 Pair Common Cathode
Supplier Device Package
SOT-23
Current - Reverse Leakage @ Vr
15 µA @ 30 V
Voltage - DC Reverse (Vr) (Max)
40 V
Operating Temperature - Junction
125°C
Voltage - Forward (Vf) (Max) @ If
550 mV @ 200 mA
Current - Average Rectified (Io) (per Diode)
200mA (DC)
| Attribute | Value |
|---|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | Schottky |
| Part Status | Active |
| Manufacturer | Panjit International Inc. |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Base Product Number | BAT721 |
| Diode Configuration | 1 Pair Common Cathode |
| Supplier Device Package | SOT-23 |
| Current - Reverse Leakage @ Vr | 15 µA @ 30 V |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Operating Temperature - Junction | 125°C |
| Voltage - Forward (Vf) (Max) @ If | 550 mV @ 200 mA |
| Current - Average Rectified (Io) (per Diode) | 200mA (DC) |
