Step1: Product
Panduit Corp PV14-P47-M
Image shown is a representation only
Manufacturer
Manufacturer No
PV14-P47-M
Packaging
Bulk
Description
CONN WIRE PIN TERM 14-16AWG
Detailed Description
Wire Pin Terminal Connector 14-16 AWG (2.5~2.0mm²) Pan-Term® Crimp
DataSheet
Color
Blue
Series
Pan-Term®
Features
Brazed Seam
Packaging
Bulk
Insulation
Insulated
Wire Gauge
14-16 AWG (2.5~2.0mm²)
Part Status
Active
Termination
Crimp
Length - Pin
0.490" (12.45mm)
Manufacturer
Panduit Corp
Pin Diameter
Circular - 0.070" (1.78mm) Dia
Contact Finish
Tin
Contact Material
Copper
Length - Overall
0.970" (24.64mm)
Base Product Number
PV14
Insulation Diameter
0.170" (4.32mm)
Length - Termination
0.480" (12.19mm)
Material - Insulation
Vinyl
| Attribute | Value |
|---|---|
| Color | Blue |
| Series | Pan-Term® |
| Features | Brazed Seam |
| Packaging | Bulk |
| Insulation | Insulated |
| Wire Gauge | 14-16 AWG (2.5~2.0mm²) |
| Part Status | Active |
| Termination | Crimp |
| Length - Pin | 0.490" (12.45mm) |
| Manufacturer | Panduit Corp |
| Pin Diameter | Circular - 0.070" (1.78mm) Dia |
| Contact Finish | Tin |
| Contact Material | Copper |
| Length - Overall | 0.970" (24.64mm) |
| Base Product Number | PV14 |
| Insulation Diameter | 0.170" (4.32mm) |
| Length - Termination | 0.480" (12.19mm) |
| Material - Insulation | Vinyl |
