Step1: Product
On Shore Technology Inc. ED100/2DSDG
Image shown is a representation only
Manufacturer
Manufacturer No
ED100/2DSDG
Packaging
Bulk
Description
TERM BLK 2POS SIDE ENTRY 5MM PCB
Detailed Description
2 Position Wire to Board Terminal Block Horizontal with Board 0.197" (5.00mm) Through Hole
Datasheet
Color
Gray
Pitch
0.197" (5.00mm)
Series
ED100/DS
Current
15 A
Voltage
300 V
Packaging
Bulk
Wire Gauge
14-22 AWG
Manufacturer
On Shore Technology Inc.
Screw Thread
M3
Mounting Type
Through Hole
Torque - Screw
0.5 Nm (4.4 Lb-In)
Housing Material
Polyamide (PA), Nylon
Number of Levels
1
Wire Termination
Screw - Leaf Spring, Wire Guard
Mating Orientation
Horizontal with Board
Base Product Number
ED100
Positions Per Level
2
Operating Temperature
-30°C ~ 105°C
Clamp Material - Plating
Steel, Stainless
| Attribute | Value |
|---|---|
| Color | Gray |
| Pitch | 0.197" (5.00mm) |
| Series | ED100/DS |
| Current | 15 A |
| Voltage | 300 V |
| Packaging | Bulk |
| Wire Gauge | 14-22 AWG |
| Manufacturer | On Shore Technology Inc. |
| Screw Thread | M3 |
| Mounting Type | Through Hole |
| Torque - Screw | 0.5 Nm (4.4 Lb-In) |
| Housing Material | Polyamide (PA), Nylon |
| Number of Levels | 1 |
| Wire Termination | Screw - Leaf Spring, Wire Guard |
| Mating Orientation | Horizontal with Board |
| Base Product Number | ED100 |
| Positions Per Level | 2 |
| Operating Temperature | -30°C ~ 105°C |
| Clamp Material - Plating | Steel, Stainless |
