Step1: Product
NXP USA Inc. SC28L202A1DGG,518
Image shown is a representation only
Manufacturer
Manufacturer No
SC28L202A1DGG,518
Package
56-TFSOP (0.240", 6.10mm Width)
Packaging
Tape & Reel (TR)
Description
IC UART DUAL W/FIFO 56-TSSOP
Detailed Description
UART IC 2, DUART Channel RS485 256 Byte 56-TSSOP
DataSheet
FIFO's
256 Byte
Series
Impact
Features
Configurable GPIO, Internal Oscillator, Timer/Counter
Protocol
RS485
Packaging
Tape & Reel (TR)
Part Status
Active
Manufacturer
NXP USA Inc.
Mounting Type
Surface Mount
Package / Case
56-TFSOP (0.240", 6.10mm Width)
Data Rate (Max)
3.125Mbps
Voltage - Supply
3.3V ~ 5V
Number of Channels
2, DUART
With Modem Control
Yes
With Auto Flow Control
Yes
Supplier Device Package
56-TSSOP
With IrDA Encoder/Decoder
No
With False Start Bit Detection
Yes
| Attribute | Value |
|---|---|
| FIFO's | 256 Byte |
| Series | Impact |
| Features | Configurable GPIO, Internal Oscillator, Timer/Counter |
| Protocol | RS485 |
| Packaging | Tape & Reel (TR) |
| Part Status | Active |
| Manufacturer | NXP USA Inc. |
| Mounting Type | Surface Mount |
| Package / Case | 56-TFSOP (0.240", 6.10mm Width) |
| Data Rate (Max) | 3.125Mbps |
| Voltage - Supply | 3.3V ~ 5V |
| Number of Channels | 2, DUART |
| With Modem Control | Yes |
| With Auto Flow Control | Yes |
| Supplier Device Package | 56-TSSOP |
| With IrDA Encoder/Decoder | No |
| With False Start Bit Detection | Yes |
