Step1: Product
NXP USA Inc. SA605DK/01,112
Image shown is a representation only
Manufacturer
Manufacturer No
SA605DK/01,112
Package
20-LSSOP (0.173", 4.40mm Width)
Packaging
Tube
Description
AUDIO SINGLE CHIP RECEIVER, FM,
Detailed Description
RF Mixer IC 0Hz ~ 500MHz 20-SSOP
DataSheet
Gain
13dB
Series
SA605
Frequency
0Hz ~ 500MHz
Packaging
Tube
Part Status
Obsolete
Manufacturer
NXP USA Inc.
Noise Figure
5dB
Mounting Type
Surface Mount
Package / Case
20-LSSOP (0.173", 4.40mm Width)
Current - Supply
5.7mA
Number of Mixers
3
Voltage - Supply
4.5V ~ 8V
Base Product Number
SA605
Supplier Device Package
20-SSOP
| Attribute | Value |
|---|---|
| Gain | 13dB |
| Series | SA605 |
| Frequency | 0Hz ~ 500MHz |
| Packaging | Tube |
| Part Status | Obsolete |
| Manufacturer | NXP USA Inc. |
| Noise Figure | 5dB |
| Mounting Type | Surface Mount |
| Package / Case | 20-LSSOP (0.173", 4.40mm Width) |
| Current - Supply | 5.7mA |
| Number of Mixers | 3 |
| Voltage - Supply | 4.5V ~ 8V |
| Base Product Number | SA605 |
| Supplier Device Package | 20-SSOP |
