Step1: Product
NXP USA Inc. BAL99/DG/B2215
Image shown is a representation only
Manufacturer
Manufacturer No
BAL99/DG/B2215
Package
TO-236-3, SC-59, SOT-23-3
Packaging
Bulk
Description
DIODE STANDARD 80V 250MA SOT233
Detailed Description
Diode 80 V 250mA Surface Mount SOT-23-3
Datasheet
Mfr
NXP USA Inc.
Grade
Automotive
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Packaging
Bulk
Technology
Standard
Mounting Type
Surface Mount
Qualification
AEC-Q101
Package / Case
TO-236-3, SC-59, SOT-23-3
Capacitance @ Vr, F
1.5pF @ 0V, 1MHz
Supplier Device Package
SOT-23-3
Reverse Recovery Time (trr)
4 ns
Current - Reverse Leakage @ Vr
1 µA @ 70 V
Voltage - DC Reverse (Vr) (Max)
80 V
Current - Average Rectified (Io)
250mA
Operating Temperature - Junction
150°C (Max)
Voltage - Forward (Vf) (Max) @ If
1.25 V @ 150 mA
| Attribute | Value |
|---|---|
| Mfr | NXP USA Inc. |
| Grade | Automotive |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Packaging | Bulk |
| Technology | Standard |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Capacitance @ Vr, F | 1.5pF @ 0V, 1MHz |
| Supplier Device Package | SOT-23-3 |
| Reverse Recovery Time (trr) | 4 ns |
| Current - Reverse Leakage @ Vr | 1 µA @ 70 V |
| Voltage - DC Reverse (Vr) (Max) | 80 V |
| Current - Average Rectified (Io) | 250mA |
| Operating Temperature - Junction | 150°C (Max) |
| Voltage - Forward (Vf) (Max) @ If | 1.25 V @ 150 mA |
