NXP Semiconductors JN5188THN/001Z
Image shown is a representation only
Manufacturer
Manufacturer No
JN5188THN/001Z
Package
40-VFQFN Exposed Pad
Packaging
Bulk
Description
IC RF TXRX+MCU 802.15.4 40HVQFN
Detailed Description
IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 40-VFQFN Exposed Pad
DataSheet
Mfr
NXP Semiconductors
GPIO
22
Type
TxRx + MCU
Protocol
Zigbee®
Frequency
2.4GHz
Packaging
Bulk
Memory Size
640kB Flash, 152kB SRAM
Part Status
Obsolete
Sensitivity
-101.3dBm
Mounting Type
Surface Mount
Package / Case
40-VFQFN Exposed Pad
Power - Output
11.2dBm
Voltage - Supply
1.9V ~ 3.6V
Serial Interfaces
I2C, SPI, PWM, UART
RF Family/Standard
802.15.4
Base Product Number
JN5188
Current - Receiving
4.3mA
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 125°C (TJ)
Current - Transmitting
7.36mA ~ 20.28mA
Supplier Device Package
40-HVQFN (6x6)
| Attribute | Value |
|---|---|
| Mfr | NXP Semiconductors |
| GPIO | 22 |
| Type | TxRx + MCU |
| Protocol | Zigbee® |
| Frequency | 2.4GHz |
| Packaging | Bulk |
| Memory Size | 640kB Flash, 152kB SRAM |
| Part Status | Obsolete |
| Sensitivity | -101.3dBm |
| Mounting Type | Surface Mount |
| Package / Case | 40-VFQFN Exposed Pad |
| Power - Output | 11.2dBm |
| Voltage - Supply | 1.9V ~ 3.6V |
| Serial Interfaces | I2C, SPI, PWM, UART |
| RF Family/Standard | 802.15.4 |
| Base Product Number | JN5188 |
| Current - Receiving | 4.3mA |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Current - Transmitting | 7.36mA ~ 20.28mA |
| Supplier Device Package | 40-HVQFN (6x6) |
