NOVOSENSE NSD56008-Q1HTSBR
Image shown is a representation only
Manufacturer
Manufacturer No
NSD56008-Q1HTSBR
Package
24-LSSOP (0.154", 3.90mm Width) Exposed Pad
Packaging
Tape & Reel (TR)
Description
8-CHANNEL LOW SIDE DRIVER
Detailed Description
Power Switch/Driver 1:01 N-Channel 500mA (Min) 24-HTSOP
DataSheet
Mfr
NOVOSENSE
Grade
Automotive
Features
Enable Input High, Slew Rate Controlled, Status Flag
Interface
Parallel, SPI
Packaging
Tape & Reel (TR)
Input Type
CMOS
Output Type
N-Channel
Part Status
Active
Switch Type
Relay, Solenoid Driver
Rds On (Typ)
1Ohm
Mounting Type
Surface Mount
Qualification
AEC-Q100
Package / Case
24-LSSOP (0.154", 3.90mm Width) Exposed Pad
Voltage - Load
-0.3V ~ 42V
Fault Protection
Current Limiting (Fixed), Open Load Detect, Over Load, Over Temperature, Over Voltage, Short Circuit, UVLO
Number of Outputs
8
Output Configuration
Low Side
Ratio - Input:Output
1:01
Operating Temperature
-40°C ~ 150°C (TJ)
Current - Output (Max)
500mA (Min)
Supplier Device Package
24-HTSOP
Voltage - Supply (Vcc/Vdd)
3.1V ~ 5.5V
| Attribute | Value |
|---|---|
| Mfr | NOVOSENSE |
| Grade | Automotive |
| Features | Enable Input High, Slew Rate Controlled, Status Flag |
| Interface | Parallel, SPI |
| Packaging | Tape & Reel (TR) |
| Input Type | CMOS |
| Output Type | N-Channel |
| Part Status | Active |
| Switch Type | Relay, Solenoid Driver |
| Rds On (Typ) | 1Ohm |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q100 |
| Package / Case | 24-LSSOP (0.154", 3.90mm Width) Exposed Pad |
| Voltage - Load | -0.3V ~ 42V |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Load, Over Temperature, Over Voltage, Short Circuit, UVLO |
| Number of Outputs | 8 |
| Output Configuration | Low Side |
| Ratio - Input:Output | 1:01 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Output (Max) | 500mA (Min) |
| Supplier Device Package | 24-HTSOP |
| Voltage - Supply (Vcc/Vdd) | 3.1V ~ 5.5V |
