Nisshinbo Micro Devices Inc. NJW4814MLE-TE1
Image shown is a representation only
Manufacturer
Manufacturer No
NJW4814MLE-TE1
Quantity
10
Availability
In Stock
Package
24-WFQFN Exposed Pad
Packaging
Tape & Reel (TR)
Description
IC HALF BRIDGE DRIVER 2A 24EQFN
Detailed Description
Half Bridge (2) Driver General Purpose Power MOSFET 24-EQFN (4x4)
DataSheet
Interface
Logic, PWM
Load Type
Inductive
Packaging
Tape & Reel (TR)
Technology
Power MOSFET
Part Status
Active
Applications
General Purpose
Manufacturer
Nisshinbo Micro Devices Inc.
Rds On (Typ)
600mOhm
Mounting Type
Surface Mount
Package / Case
24-WFQFN Exposed Pad
Voltage - Load
2.7V ~ 5.5V
Fault Protection
Over Current, Over Voltage
Voltage - Supply
2.7V ~ 5.5V
Base Product Number
NJW4814
Output Configuration
Half Bridge (2)
Operating Temperature
-40°C ~ 150°C (TJ)
Supplier Device Package
24-EQFN (4x4)
Current - Output / Channel
2A
| Attribute | Value |
|---|---|
| Interface | Logic, PWM |
| Load Type | Inductive |
| Packaging | Tape & Reel (TR) |
| Technology | Power MOSFET |
| Part Status | Active |
| Applications | General Purpose |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Rds On (Typ) | 600mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 24-WFQFN Exposed Pad |
| Voltage - Load | 2.7V ~ 5.5V |
| Fault Protection | Over Current, Over Voltage |
| Voltage - Supply | 2.7V ~ 5.5V |
| Base Product Number | NJW4814 |
| Output Configuration | Half Bridge (2) |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Supplier Device Package | 24-EQFN (4x4) |
| Current - Output / Channel | 2A |
