Step1: Product
Nexperia USA Inc. BSS138PS,115
Image shown is a representation only
Manufacturer
Manufacturer No
BSS138PS,115
Quantity
83170
Availability
In Stock
Package
6-TSSOP, SC-88, SOT-363
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MOSFET 2N-CH 60V 0.32A 6TSSOP
Detailed Description
Mosfet Array 60V 320mA 420mW Surface Mount 6-TSSOP
DataSheet
Grade
Automotive
Series
TrenchMOS™
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
MOSFET (Metal Oxide)
FET Feature
Logic Level Gate
Part Status
Active
Power - Max
420mW
Manufacturer
Nexperia USA Inc.
Configuration
2 N-Channel (Dual)
Mounting Type
Surface Mount
Qualification
AEC-Q101
Package / Case
6-TSSOP, SC-88, SOT-363
Vgs(th) (Max) @ Id
1.5V @ 250µA
Base Product Number
BSS138
Operating Temperature
150°C (TJ)
Rds On (Max) @ Id, Vgs
1.6Ohm @ 300mA, 10V
Supplier Device Package
6-TSSOP
Gate Charge (Qg) (Max) @ Vgs
0.8nC @ 4.5V
Drain to Source Voltage (Vdss)
60V
Input Capacitance (Ciss) (Max) @ Vds
50pF @ 10V
Current - Continuous Drain (Id) @ 25°C
320mA
| Attribute | Value |
|---|---|
| Grade | Automotive |
| Series | TrenchMOS™ |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | MOSFET (Metal Oxide) |
| FET Feature | Logic Level Gate |
| Part Status | Active |
| Power - Max | 420mW |
| Manufacturer | Nexperia USA Inc. |
| Configuration | 2 N-Channel (Dual) |
| Mounting Type | Surface Mount |
| Qualification | AEC-Q101 |
| Package / Case | 6-TSSOP, SC-88, SOT-363 |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Base Product Number | BSS138 |
| Operating Temperature | 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 1.6Ohm @ 300mA, 10V |
| Supplier Device Package | 6-TSSOP |
| Gate Charge (Qg) (Max) @ Vgs | 0.8nC @ 4.5V |
| Drain to Source Voltage (Vdss) | 60V |
| Input Capacitance (Ciss) (Max) @ Vds | 50pF @ 10V |
| Current - Continuous Drain (Id) @ 25°C | 320mA |
