Step1: Product
Murata Power Solutions Inc. BAC10S24DC
Image shown is a representation only
Manufacturer
Manufacturer No
BAC10S24DC
Package
4-DIP Module
Packaging
Tube
Description
AC/DC CONVERTER 24V 10W
Detailed Description
Enclosed AC DC Converters 1 Output 24V 420mA 85 ~ 264 VAC, 120 ~ 370 VDC Input
DataSheet
Type
Enclosed
Series
BAC10 (10W)
Features
Universal Input
Packaging
Tube
Efficiency
83.5%
Part Status
Last Time Buy
Applications
ITE (Commercial), Medical
Manufacturer
Murata Power Solutions Inc.
Mounting Type
Through Hole
Power (Watts)
10 W
Package / Case
4-DIP Module
Approval Agency
CE, cURus
Line Regulation
±0.5%
Load Regulation
±1%
Standard Number
60601-1; 62368-1
Voltage - Input
85 ~ 264 VAC, 120 ~ 370 VDC
Size / Dimension
1.52" L x 1.08" W x 0.65" H (38.6mm x 27.4mm x 16.6mm)
Number of Outputs
1
Voltage - Output 1
24V
Operating Temperature
-40°C ~ 85°C (With Derating)
Current - Output (Max)
420mA
| Attribute | Value |
|---|---|
| Type | Enclosed |
| Series | BAC10 (10W) |
| Features | Universal Input |
| Packaging | Tube |
| Efficiency | 83.5% |
| Part Status | Last Time Buy |
| Applications | ITE (Commercial), Medical |
| Manufacturer | Murata Power Solutions Inc. |
| Mounting Type | Through Hole |
| Power (Watts) | 10 W |
| Package / Case | 4-DIP Module |
| Approval Agency | CE, cURus |
| Line Regulation | ±0.5% |
| Load Regulation | ±1% |
| Standard Number | 60601-1; 62368-1 |
| Voltage - Input | 85 ~ 264 VAC, 120 ~ 370 VDC |
| Size / Dimension | 1.52" L x 1.08" W x 0.65" H (38.6mm x 27.4mm x 16.6mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 24V |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Current - Output (Max) | 420mA |
