Step1: Product
Molex 0848569104
Image shown is a representation only
Manufacturer
Manufacturer No
0848569104
Packaging
Bulk
Description
NMEA MINI,5/C, M/F/F WITH MINI D
Detailed Description
Circular Connector Distributor T-Shaped 5/5 (2) Female Sockets/Female Sockets (1), Male Pins (1) Free Hanging (In-Line)
DataSheet
Series
Brad Mini-Change 84856
Features
Coupling Nut
Packaging
Bulk
Shielding
Unshielded
Part Status
Active
Manufacturer
Molex
Housing Color
Black
Mounting Type
Free Hanging (In-Line)
Fastening Type
Threaded
Voltage Rating
300V
Connector Style
Distributor T-Shaped
Housing Material
Thermoplastic Elastomer (TPE)
Primary Material
Plastic
Ingress Protection
IP67 - Dust Tight, Waterproof
Base Product Number
084856
Current Rating (Amps)
2A
Operating Temperature
-20°C ~ 80°C
Convert To (Adapter End)
Female Sockets (1), Male Pins (1)
Orientation (Convert To)
Keyed
Convert From (Adapter End)
Female Sockets
Orientation (Convert From)
Keyed
Number of Positions (Convert To)
5 (2)
Shell Size - Insert (Convert To)
7/8"
Number of Positions (Convert From)
5
Shell Size - Insert (Convert From)
7/8"
| Attribute | Value |
|---|---|
| Series | Brad Mini-Change 84856 |
| Features | Coupling Nut |
| Packaging | Bulk |
| Shielding | Unshielded |
| Part Status | Active |
| Manufacturer | Molex |
| Housing Color | Black |
| Mounting Type | Free Hanging (In-Line) |
| Fastening Type | Threaded |
| Voltage Rating | 300V |
| Connector Style | Distributor T-Shaped |
| Housing Material | Thermoplastic Elastomer (TPE) |
| Primary Material | Plastic |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Base Product Number | 084856 |
| Current Rating (Amps) | 2A |
| Operating Temperature | -20°C ~ 80°C |
| Convert To (Adapter End) | Female Sockets (1), Male Pins (1) |
| Orientation (Convert To) | Keyed |
| Convert From (Adapter End) | Female Sockets |
| Orientation (Convert From) | Keyed |
| Number of Positions (Convert To) | 5 (2) |
| Shell Size - Insert (Convert To) | 7/8" |
| Number of Positions (Convert From) | 5 |
| Shell Size - Insert (Convert From) | 7/8" |
