Step1: Product
Molex 0784990002
Image shown is a representation only
Manufacturer
Manufacturer No
0784990002
Packaging
Tape & Reel (TR)
Description
CONN CAM SOCKET 24POS GOLD
Detailed Description
24 (2 x 4, 2 x 8) Pos Camera Socket Socket Gold Surface Mount
DataSheet
Type
Camera Socket
Series
78499
Features
Closed Frame
Packaging
Tape & Reel (TR)
Part Status
Obsolete
Termination
Solder
Manufacturer
Molex
Pitch - Post
0.024" (0.60mm)
Mounting Type
Surface Mount
Pitch - Mating
0.024" (0.60mm)
Housing Material
Plastic
Contact Resistance
80mOhm
Base Product Number
078499
Contact Finish - Post
Gold
Current Rating (Amps)
0.5 A
Operating Temperature
-55°C ~ 85°C
Contact Finish - Mating
Gold
Contact Material - Post
Copper Alloy
Contact Material - Mating
Copper Alloy
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
Flash
Contact Finish Thickness - Mating
12.0µin (0.30µm)
Number of Positions or Pins (Grid)
24 (2 x 4, 2 x 8)
| Attribute | Value |
|---|---|
| Type | Camera Socket |
| Series | 78499 |
| Features | Closed Frame |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Termination | Solder |
| Manufacturer | Molex |
| Pitch - Post | 0.024" (0.60mm) |
| Mounting Type | Surface Mount |
| Pitch - Mating | 0.024" (0.60mm) |
| Housing Material | Plastic |
| Contact Resistance | 80mOhm |
| Base Product Number | 078499 |
| Contact Finish - Post | Gold |
| Current Rating (Amps) | 0.5 A |
| Operating Temperature | -55°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Contact Material - Post | Copper Alloy |
| Contact Material - Mating | Copper Alloy |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | 12.0µin (0.30µm) |
| Number of Positions or Pins (Grid) | 24 (2 x 4, 2 x 8) |
