CONN HEADER SMD 20POS 1.27MM
Detailed Description
Connector Header Surface Mount 20 position 0.050" (1.27mm)
DataSheet
Mfr
Mill-Max Manufacturing Corp.
Style
Board to Board
Series
852
Packaging
Bulk
Shrouding
Unshrouded
Part Status
Active
Termination
Solder
Contact Type
Male Pin
Contact Shape
Circular
Mounting Type
Surface Mount
Connector Type
Header
Fastening Type
Push-Pull
Number of Rows
2
Pitch - Mating
0.050" (1.27mm)
Contact Material
Brass Alloy
Insulation Color
Black
Insulation Height
0.075" (1.90mm)
Base Product Number
852-90
Insulation Material
Polyamide (PA46), Nylon 4/6
Number of Positions
20
Row Spacing - Mating
0.050" (1.27mm)
Contact Finish - Post
Tin-Lead
Contact Finish - Mating
Tin-Lead
Contact Length - Mating
0.118" (3.00mm)
Number of Positions Loaded
All
Contact Finish Thickness - Post
200.0µin (5.08µm)
Contact Finish Thickness - Mating
200.0µin (5.08µm)
| Attribute | Value |
|---|---|
| Mfr | Mill-Max Manufacturing Corp. |
| Style | Board to Board |
| Series | 852 |
| Packaging | Bulk |
| Shrouding | Unshrouded |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Male Pin |
| Contact Shape | Circular |
| Mounting Type | Surface Mount |
| Connector Type | Header |
| Fastening Type | Push-Pull |
| Number of Rows | 2 |
| Pitch - Mating | 0.050" (1.27mm) |
| Contact Material | Brass Alloy |
| Insulation Color | Black |
| Insulation Height | 0.075" (1.90mm) |
| Base Product Number | 852-90 |
| Insulation Material | Polyamide (PA46), Nylon 4/6 |
| Number of Positions | 20 |
| Row Spacing - Mating | 0.050" (1.27mm) |
| Contact Finish - Post | Tin-Lead |
| Contact Finish - Mating | Tin-Lead |
| Contact Length - Mating | 0.118" (3.00mm) |
| Number of Positions Loaded | All |
| Contact Finish Thickness - Post | 200.0µin (5.08µm) |
| Contact Finish Thickness - Mating | 200.0µin (5.08µm) |
