Step1: Product
MicroPower Direct MD105S-03BR
Image shown is a representation only
Manufacturer
Manufacturer No
MD105S-03BR
Packaging
Tube
Description
DC/DC,1W,5V IN,3V OUT,1 KV,
Detailed Description
Isolated Module DC DC Converter 1 Output 3.3V 250mA 4.75V - 5.25V Input
DataSheet
Mfr
MicroPower Direct
Type
Isolated Module
Series
MD100BR
Features
Proportional Output, SCP
Packaging
Tube
Efficiency
67%
Part Status
Active
Applications
Industrial, ITE (Commercial)
Mounting Type
Through Hole
Power (Watts)
1 W
Approval Agency
CE
Control Features
Enable, Active High
Size / Dimension
0.77" L x 0.40" W x 0.24" H (19.5mm x 10.2mm x 6.0mm)
Number of Outputs
1
Voltage - Output 1
3.3V
Voltage - Isolation
1.5 kV
Operating Temperature
-40°C ~ 85°C
Voltage - Input (Max)
5.25V
Voltage - Input (Min)
4.75V
Current - Output (Max)
250mA
| Attribute | Value |
|---|---|
| Mfr | MicroPower Direct |
| Type | Isolated Module |
| Series | MD100BR |
| Features | Proportional Output, SCP |
| Packaging | Tube |
| Efficiency | 67% |
| Part Status | Active |
| Applications | Industrial, ITE (Commercial) |
| Mounting Type | Through Hole |
| Power (Watts) | 1 W |
| Approval Agency | CE |
| Control Features | Enable, Active High |
| Size / Dimension | 0.77" L x 0.40" W x 0.24" H (19.5mm x 10.2mm x 6.0mm) |
| Number of Outputs | 1 |
| Voltage - Output 1 | 3.3V |
| Voltage - Isolation | 1.5 kV |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Input (Max) | 5.25V |
| Voltage - Input (Min) | 4.75V |
| Current - Output (Max) | 250mA |
