Microchip Technology PIC32CX5109BZ31048-V/ZWX
Image shown is a representation only
Manufacturer
Manufacturer No
PIC32CX5109BZ31048-V/ZWX
Quantity
10
Availability
In Stock
Package
48-VFQFN Exposed Pad
Packaging
Tray
Description
IC RF TXRX+MCU 802.15.4 48VQFN
Detailed Description
IC RF TxRx + MCU 802.15.4, Bluetooth Bluetooth v6.0, Zigbee® 2.4GHz 48-VFQFN Exposed Pad
DataSheet
Mfr
Microchip Technology
GPIO
27
Type
TxRx + MCU
Grade
Automotive
Series
PIC32CX-BZ3
Protocol
Bluetooth v6.0, Zigbee®
Frequency
2.4GHz
Packaging
Tray
Modulation
GFSK, O-QPSK
Memory Size
512kB Flash, 96kB SRAM
Part Status
Active
Sensitivity
-108dBm
Mounting Type
Surface Mount, Wettable Flank
Qualification
AEC-Q100
Package / Case
48-VFQFN Exposed Pad
Power - Output
11dBm
Data Rate (Max)
2Mbps
Voltage - Supply
1.9V ~ 3.6V
Serial Interfaces
ADC, GPIO, I2C, PWM, SPI, USART
RF Family/Standard
802.15.4, Bluetooth
Base Product Number
PIC32CX5109
Current - Receiving
16mA ~ 20mA
Operating Temperature
-40°C ~ 105°C
Current - Transmitting
22mA ~ 49mA
Supplier Device Package
48-VQFN (6x6)
| Attribute | Value |
|---|---|
| Mfr | Microchip Technology |
| GPIO | 27 |
| Type | TxRx + MCU |
| Grade | Automotive |
| Series | PIC32CX-BZ3 |
| Protocol | Bluetooth v6.0, Zigbee® |
| Frequency | 2.4GHz |
| Packaging | Tray |
| Modulation | GFSK, O-QPSK |
| Memory Size | 512kB Flash, 96kB SRAM |
| Part Status | Active |
| Sensitivity | -108dBm |
| Mounting Type | Surface Mount, Wettable Flank |
| Qualification | AEC-Q100 |
| Package / Case | 48-VFQFN Exposed Pad |
| Power - Output | 11dBm |
| Data Rate (Max) | 2Mbps |
| Voltage - Supply | 1.9V ~ 3.6V |
| Serial Interfaces | ADC, GPIO, I2C, PWM, SPI, USART |
| RF Family/Standard | 802.15.4, Bluetooth |
| Base Product Number | PIC32CX5109 |
| Current - Receiving | 16mA ~ 20mA |
| Operating Temperature | -40°C ~ 105°C |
| Current - Transmitting | 22mA ~ 49mA |
| Supplier Device Package | 48-VQFN (6x6) |
