Step1: Product
MCC (Micro Commercial Components) AZ23C13W-TP
Image shown is a representation only
Manufacturer
Manufacturer No
AZ23C13W-TP
Quantity
10
Availability
In Stock
Package
SC-70, SOT-323
Packaging
Bulk
Description
DIODE ZENER ARRAY 13V SOT-323
Detailed Description
Zener Diode Array 1 Pair Common Anode 13 V 200 mW ±5% SOT-323
DataSheet
Packaging
Bulk
Tolerance
±5%
Part Status
Active
Power - Max
200 mW
Manufacturer
MCC (Micro Commercial Components)
Configuration
1 Pair Common Anode
Mounting Type
Surface Mount
Package / Case
SC-70, SOT-323
Base Product Number
AZ23C13
Impedance (Max) (Zzt)
25 Ohms
Supplier Device Package
SOT-323
Voltage - Zener (Nom) (Vz)
13 V
Current - Reverse Leakage @ Vr
100 nA @ 10 V
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Tolerance | ±5% |
| Part Status | Active |
| Power - Max | 200 mW |
| Manufacturer | MCC (Micro Commercial Components) |
| Configuration | 1 Pair Common Anode |
| Mounting Type | Surface Mount |
| Package / Case | SC-70, SOT-323 |
| Base Product Number | AZ23C13 |
| Impedance (Max) (Zzt) | 25 Ohms |
| Supplier Device Package | SOT-323 |
| Voltage - Zener (Nom) (Vz) | 13 V |
| Current - Reverse Leakage @ Vr | 100 nA @ 10 V |
