Step1: Product
Master Electronics AR7-11H12
Image shown is a representation only
Manufacturer
Manufacturer No
AR7-11H12
Packaging
Bulk
Description
Relay SPST-NO 24V 70A .250" QC
Detailed Description
Automotive Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
DataSheet
Series
AR
Features
IP54 - Dust Protected, Water Resistant
Coil Type
Non Latching
Packaging
Bulk
Coil Power
1.9W
Part Status
Active
Coil Voltage
24VDC
Contact Form
SPST-NO (1 Form A)
Manufacturer
Master Electronics
Mounting Type
Through Hole
Coil Resistance
303 Ohms
Contact Material
Silver Tin Oxide (AgSnO)
Switching Voltage
75VDC - Max
Termination Style
PC Pin
Must Operate Voltage
14.4 VDC
Must Release Voltage
2.4 VDC
Operating Temperature
-40°C ~ 105°C
Contact Rating (Current)
70 A
| Attribute | Value |
|---|---|
| Series | AR |
| Features | IP54 - Dust Protected, Water Resistant |
| Coil Type | Non Latching |
| Packaging | Bulk |
| Coil Power | 1.9W |
| Part Status | Active |
| Coil Voltage | 24VDC |
| Contact Form | SPST-NO (1 Form A) |
| Manufacturer | Master Electronics |
| Mounting Type | Through Hole |
| Coil Resistance | 303 Ohms |
| Contact Material | Silver Tin Oxide (AgSnO) |
| Switching Voltage | 75VDC - Max |
| Termination Style | PC Pin |
| Must Operate Voltage | 14.4 VDC |
| Must Release Voltage | 2.4 VDC |
| Operating Temperature | -40°C ~ 105°C |
| Contact Rating (Current) | 70 A |
