Step1: Product
Lite-On Inc. LTV-7840S-TA1
Image shown is a representation only
Manufacturer
Manufacturer No
LTV-7840S-TA1
Package
8-DIP (0.300", 7.62mm)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
ANALOG, CURRENT/VOLTAGE SENSOR
Detailed Description
Gate Driver Optical Coupling 5000Vrms 1 Channel 8-DIP
DataSheet
Mfr
Lite-On Inc.
Series
LTV-6314
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
Optical Coupling
Part Status
Active
Mounting Type
Through Hole
Package / Case
8-DIP (0.300", 7.62mm)
Approval Agency
cUL, IEC/EN/DIN, UL, VDE
Number of Channels
1
Voltage - Isolation
5000Vrms
Operating Temperature
-40°C ~ 85°C
Rise / Fall Time (Typ)
6.6µs, 6.6µs (Max)
Supplier Device Package
8-DIP
Voltage - Output Supply
4.5V ~ 5.5V
Common Mode Transient Immunity (Min)
10kV/µs
| Attribute | Value |
|---|---|
| Mfr | Lite-On Inc. |
| Series | LTV-6314 |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | Optical Coupling |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | 8-DIP (0.300", 7.62mm) |
| Approval Agency | cUL, IEC/EN/DIN, UL, VDE |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Operating Temperature | -40°C ~ 85°C |
| Rise / Fall Time (Typ) | 6.6µs, 6.6µs (Max) |
| Supplier Device Package | 8-DIP |
| Voltage - Output Supply | 4.5V ~ 5.5V |
| Common Mode Transient Immunity (Min) | 10kV/µs |
