Lite-On Inc. CNY17F-3
Image shown is a representation only
Manufacturer
Manufacturer No
CNY17F-3
Quantity
20000
Availability
In Stock
Package
6-DIP (0.300", 7.62mm)
Packaging
Tube
Description
OPTOISOLATOR 5KV 1CH TRANS 6-DIP
Detailed Description
Optoisolator Transistor Output 5000Vrms 1 Channel 6-DIP
DataSheet
Series
CNY17F
Packaging
Tube
Input Type
DC
Output Type
Transistor
Part Status
Active
Manufacturer
Lite-On Inc.
Mounting Type
Through Hole
Package / Case
6-DIP (0.300", 7.62mm)
Number of Channels
1
Base Product Number
CNY17
Voltage - Isolation
5000Vrms
Vce Saturation (Max)
300mV
Operating Temperature
-55°C ~ 100°C
Rise / Fall Time (Typ)
5µs, 5µs
Voltage - Output (Max)
70V
Supplier Device Package
6-DIP
Current - Output / Channel
150mA
Current Transfer Ratio (Max)
200% @ 10mA
Current Transfer Ratio (Min)
100% @ 10mA
Voltage - Forward (Vf) (Typ)
1.45V
Current - DC Forward (If) (Max)
60 mA
| Attribute | Value |
|---|---|
| Series | CNY17F |
| Packaging | Tube |
| Input Type | DC |
| Output Type | Transistor |
| Part Status | Active |
| Manufacturer | Lite-On Inc. |
| Mounting Type | Through Hole |
| Package / Case | 6-DIP (0.300", 7.62mm) |
| Number of Channels | 1 |
| Base Product Number | CNY17 |
| Voltage - Isolation | 5000Vrms |
| Vce Saturation (Max) | 300mV |
| Operating Temperature | -55°C ~ 100°C |
| Rise / Fall Time (Typ) | 5µs, 5µs |
| Voltage - Output (Max) | 70V |
| Supplier Device Package | 6-DIP |
| Current - Output / Channel | 150mA |
| Current Transfer Ratio (Max) | 200% @ 10mA |
| Current Transfer Ratio (Min) | 100% @ 10mA |
| Voltage - Forward (Vf) (Typ) | 1.45V |
| Current - DC Forward (If) (Max) | 60 mA |
