Step1: Product
KYOCERA AVX TCF20B60
Image shown is a representation only
Manufacturer
Manufacturer No
TCF20B60
Package
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Packaging
Tape & Reel (TR)
Description
DIODE STANDARD 600V 20A TO263
Detailed Description
Diode 600 V 20A Surface Mount TO-263 (D2PAK)
DataSheet
Mfr
KYOCERA AVX
Speed
Fast Recovery =< 500ns, > 200mA (Io)
Packaging
Tape & Reel (TR)
Technology
Standard
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Base Product Number
TCF20
Supplier Device Package
TO-263 (D2PAK)
Reverse Recovery Time (trr)
50 ns
Current - Reverse Leakage @ Vr
30 µA @ 600 V
Voltage - DC Reverse (Vr) (Max)
600 V
Current - Average Rectified (Io)
20A
Operating Temperature - Junction
-40°C ~ 150°C
Voltage - Forward (Vf) (Max) @ If
1.8 V @ 10 A
| Attribute | Value |
|---|---|
| Mfr | KYOCERA AVX |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Packaging | Tape & Reel (TR) |
| Technology | Standard |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2PAK (2 Leads + Tab), TO-263AB |
| Base Product Number | TCF20 |
| Supplier Device Package | TO-263 (D2PAK) |
| Reverse Recovery Time (trr) | 50 ns |
| Current - Reverse Leakage @ Vr | 30 µA @ 600 V |
| Voltage - DC Reverse (Vr) (Max) | 600 V |
| Current - Average Rectified (Io) | 20A |
| Operating Temperature - Junction | -40°C ~ 150°C |
| Voltage - Forward (Vf) (Max) @ If | 1.8 V @ 10 A |
