Step1: Product
Kingbright PSA12-11SURKWA
Image shown is a representation only
Manufacturer
Manufacturer No
PSA12-11SURKWA
Package
18-DIP (0.800", 20.32mm)
Packaging
Bulk
Description
1.2" RED ALPHANUMERIC LED DISPLA
Detailed Description
Display Modules - LED Character and Numeric Red 16-Segment, Alphanumeric 1 Character Common Anode 1.85V, 3.7V 10mA 1.575" H x 1.083" W x 0.453" D (40.00mm x 27.50mm x 11.50mm) 18-DIP (0.800", 20.32mm)
Datasheet
Color
Red
Packaging
Bulk
Common Pin
Common Anode
Display Type
16-Segment, Alphanumeric
Manufacturer
Kingbright
Current - Test
10mA
Package / Case
18-DIP (0.800", 20.32mm)
Digit/Alpha Size
1.20" (30.48mm)
Size / Dimension
1.575" H x 1.083" W x 0.453" D (40.00mm x 27.50mm x 11.50mm)
Wavelength - Peak
645nm
Base Product Number
PSA12
Millicandela Rating
63mcd
Number of Characters
1
Power Dissipation (Max)
75mW
Voltage - Forward (Vf) (Typ)
1.85V, 3.7V
| Attribute | Value |
|---|---|
| Color | Red |
| Packaging | Bulk |
| Common Pin | Common Anode |
| Display Type | 16-Segment, Alphanumeric |
| Manufacturer | Kingbright |
| Current - Test | 10mA |
| Package / Case | 18-DIP (0.800", 20.32mm) |
| Digit/Alpha Size | 1.20" (30.48mm) |
| Size / Dimension | 1.575" H x 1.083" W x 0.453" D (40.00mm x 27.50mm x 11.50mm) |
| Wavelength - Peak | 645nm |
| Base Product Number | PSA12 |
| Millicandela Rating | 63mcd |
| Number of Characters | 1 |
| Power Dissipation (Max) | 75mW |
| Voltage - Forward (Vf) (Typ) | 1.85V, 3.7V |
