Step1: Product
Keystone Electronics 1509-4
Image shown is a representation only
Manufacturer
Manufacturer No
1509-4
Packaging
Bulk
Description
TERM TURRET HOLLOW L=7.92MM TIN
Detailed Description
Terminal Turret Connector Single End, Hollow 0.312" (7.92mm) Tin
Datasheet
Packaging
Bulk
Insulation
Non-Insulated
Termination
Staking Flare
Manufacturer
Keystone Electronics
Mounting Type
Through Hole
Terminal Type
Single End, Hollow
Contact Finish
Tin
Board Thickness
0.125" (3.18mm)
Flange Diameter
0.187" (4.75mm)
Staking Side OD
0.112" (2.84mm)
Contact Material
Brass
Length - Overall
0.483" (12.27mm)
Number of Turrets
Double
Length - Above Board
0.312" (7.92mm)
Length - Below Flange
0.171" (4.34mm)
Diameter - Turret Head
0.150" (3.81mm)
Mounting Hole Diameter
0.116" (2.95mm)
| Attribute | Value |
|---|---|
| Packaging | Bulk |
| Insulation | Non-Insulated |
| Termination | Staking Flare |
| Manufacturer | Keystone Electronics |
| Mounting Type | Through Hole |
| Terminal Type | Single End, Hollow |
| Contact Finish | Tin |
| Board Thickness | 0.125" (3.18mm) |
| Flange Diameter | 0.187" (4.75mm) |
| Staking Side OD | 0.112" (2.84mm) |
| Contact Material | Brass |
| Length - Overall | 0.483" (12.27mm) |
| Number of Turrets | Double |
| Length - Above Board | 0.312" (7.92mm) |
| Length - Below Flange | 0.171" (4.34mm) |
| Diameter - Turret Head | 0.150" (3.81mm) |
| Mounting Hole Diameter | 0.116" (2.95mm) |
