Step1: Product
KEMET SBT-0208
Image shown is a representation only
Manufacturer
Manufacturer No
SBT-0208
Package
Vertical, 2 PC Pin
Packaging
Bulk
Description
FIXED IND 8UH 500MA 20 MOHM TH
Detailed Description
8 µH Unshielded Toroidal Inductor 500 mA 20mOhm Max Vertical, 2 PC Pin
DataSheet
Mfr
KEMET
Type
Toroidal
Series
SBT
Packaging
Bulk
Shielding
Unshielded
Tolerance
±50%
Inductance
8 µH
Part Status
Active
Mounting Type
Through Hole
Package / Case
Vertical, 2 PC Pin
Material - Core
Nickel Zinc Ferrite (NiZn)
Size / Dimension
0.295" L x 0.118" W (7.50mm x 3.00mm)
Base Product Number
SBT-020
DC Resistance (DCR)
20mOhm Max
Current Rating (Amps)
500 mA
Height - Seated (Max)
0.343" (8.70mm)
Operating Temperature
-25°C ~ 70°C
Inductance Frequency - Test
1 kHz
| Attribute | Value |
|---|---|
| Mfr | KEMET |
| Type | Toroidal |
| Series | SBT |
| Packaging | Bulk |
| Shielding | Unshielded |
| Tolerance | ±50% |
| Inductance | 8 µH |
| Part Status | Active |
| Mounting Type | Through Hole |
| Package / Case | Vertical, 2 PC Pin |
| Material - Core | Nickel Zinc Ferrite (NiZn) |
| Size / Dimension | 0.295" L x 0.118" W (7.50mm x 3.00mm) |
| Base Product Number | SBT-020 |
| DC Resistance (DCR) | 20mOhm Max |
| Current Rating (Amps) | 500 mA |
| Height - Seated (Max) | 0.343" (8.70mm) |
| Operating Temperature | -25°C ~ 70°C |
| Inductance Frequency - Test | 1 kHz |
