JAE Electronics PS-10SD-D4TS1-1
Image shown is a representation only
Manufacturer
Manufacturer No
PS-10SD-D4TS1-1
Quantity
10
Availability
In Stock
Packaging
Bulk
Description
CONN RCPT 10POS 0.1 GOLD PCB
Detailed Description
10 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold
DataSheet
Mfr
JAE Electronics
Style
Board to Board
Series
PS
Packaging
Bulk
Part Status
Active
Termination
Solder
Contact Type
Female Socket
Contact Shape
Square
Mounting Type
Through Hole
Connector Type
Receptacle
Fastening Type
Push-Pull
Number of Rows
2
Pitch - Mating
0.100" (2.54mm)
Contact Material
Copper Alloy
Insulation Color
Black
Insulation Height
0.374" (9.50mm)
Base Product Number
PS-10SD
Insulation Material
Polybutylene Terephthalate (PBT)
Number of Positions
10
Row Spacing - Mating
0.100" (2.54mm)
Contact Finish - Post
Gold
Contact Length - Post
0.115" (2.92mm)
Current Rating (Amps)
3A
Operating Temperature
-55°C ~ 85°C
Contact Finish - Mating
Gold
Number of Positions Loaded
All
Material Flammability Rating
UL94 V-0
Contact Finish Thickness - Post
Flash
Contact Finish Thickness - Mating
3.90µin (0.099µm)
| Attribute | Value |
|---|---|
| Mfr | JAE Electronics |
| Style | Board to Board |
| Series | PS |
| Packaging | Bulk |
| Part Status | Active |
| Termination | Solder |
| Contact Type | Female Socket |
| Contact Shape | Square |
| Mounting Type | Through Hole |
| Connector Type | Receptacle |
| Fastening Type | Push-Pull |
| Number of Rows | 2 |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Material | Copper Alloy |
| Insulation Color | Black |
| Insulation Height | 0.374" (9.50mm) |
| Base Product Number | PS-10SD |
| Insulation Material | Polybutylene Terephthalate (PBT) |
| Number of Positions | 10 |
| Row Spacing - Mating | 0.100" (2.54mm) |
| Contact Finish - Post | Gold |
| Contact Length - Post | 0.115" (2.92mm) |
| Current Rating (Amps) | 3A |
| Operating Temperature | -55°C ~ 85°C |
| Contact Finish - Mating | Gold |
| Number of Positions Loaded | All |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish Thickness - Post | Flash |
| Contact Finish Thickness - Mating | 3.90µin (0.099µm) |
