Step1: Product
JAE Electronics JL05-2A20-15SC-F0-RK
Image shown is a representation only
Manufacturer
Manufacturer No
JL05-2A20-15SC-F0-RK
Packaging
Bulk
Description
Interconnect Circular
Detailed Description
7 (6 + PE) Position Circular Connector Receptacle Housing Panel Mount
Datasheet
Note
Contacts Sold Separately
Type
For Female Sockets
Series
JL05
Packaging
Bulk
Shielding
Unshielded
Orientation
N (Normal)
Contact Size
12
Contact Type
Crimp
Manufacturer
JAE Electronics
Shell Finish
Zinc
Contact Shape
Circular
Housing Color
Black
Mounting Type
Panel Mount
Connector Type
Receptacle Housing
Fastening Type
Bayonet Lock
Shell Material
Aluminum
Insert Material
Synthetic Resin
Mounting Feature
Flange
Primary Material
Metal
Ingress Protection
IP67 - Dust Tight, Waterproof
Number of Positions
7 (6 + PE)
Shell Size - Insert
20-15
Operating Temperature
-55°C ~ 125°C
Material Flammability Rating
UL94 V-0
| Attribute | Value |
|---|---|
| Note | Contacts Sold Separately |
| Type | For Female Sockets |
| Series | JL05 |
| Packaging | Bulk |
| Shielding | Unshielded |
| Orientation | N (Normal) |
| Contact Size | 12 |
| Contact Type | Crimp |
| Manufacturer | JAE Electronics |
| Shell Finish | Zinc |
| Contact Shape | Circular |
| Housing Color | Black |
| Mounting Type | Panel Mount |
| Connector Type | Receptacle Housing |
| Fastening Type | Bayonet Lock |
| Shell Material | Aluminum |
| Insert Material | Synthetic Resin |
| Mounting Feature | Flange |
| Primary Material | Metal |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Number of Positions | 7 (6 + PE) |
| Shell Size - Insert | 20-15 |
| Operating Temperature | -55°C ~ 125°C |
| Material Flammability Rating | UL94 V-0 |
