IXYS Integrated Circuits Division IX332B
Image shown is a representation only
Manufacturer
Manufacturer No
IX332B
Package
16-SOIC (0.295", 7.50mm Width)
Packaging
Tube
Description
OPTOISO 4.25KV 2CH GT DVR 16SOIC
Detailed Description
2.5A Gate Driver Optical Coupling 4250Vrms 2 Channel 16-SOIC
DataSheet
Mfr
IXYS Integrated Circuits Division
Packaging
Tube
Technology
Optical Coupling
Part Status
Obsolete
Mounting Type
Surface Mount
Package / Case
16-SOIC (0.295", 7.50mm Width)
Approval Agency
CSA, UL1577
Number of Channels
2
Base Product Number
IX332
Voltage - Isolation
4250Vrms
Current - Peak Output
2.5A
Operating Temperature
-40°C ~ 105°C
Rise / Fall Time (Typ)
13ns, 10ns
Supplier Device Package
16-SOIC
Voltage - Output Supply
15V ~ 30V
Current - Output High, Low
500mA, 500mA
Pulse Width Distortion (Max)
100ns
Voltage - Forward (Vf) (Typ)
1.4V
Current - DC Forward (If) (Max)
20 mA
Propagation Delay tpLH / tpHL (Max)
220ns, 220ns
Common Mode Transient Immunity (Min)
50kV/µs
| Attribute | Value |
|---|---|
| Mfr | IXYS Integrated Circuits Division |
| Packaging | Tube |
| Technology | Optical Coupling |
| Part Status | Obsolete |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) |
| Approval Agency | CSA, UL1577 |
| Number of Channels | 2 |
| Base Product Number | IX332 |
| Voltage - Isolation | 4250Vrms |
| Current - Peak Output | 2.5A |
| Operating Temperature | -40°C ~ 105°C |
| Rise / Fall Time (Typ) | 13ns, 10ns |
| Supplier Device Package | 16-SOIC |
| Voltage - Output Supply | 15V ~ 30V |
| Current - Output High, Low | 500mA, 500mA |
| Pulse Width Distortion (Max) | 100ns |
| Voltage - Forward (Vf) (Typ) | 1.4V |
| Current - DC Forward (If) (Max) | 20 mA |
| Propagation Delay tpLH / tpHL (Max) | 220ns, 220ns |
| Common Mode Transient Immunity (Min) | 50kV/µs |
