Isocom Components 2004 LTD ICPLW137SMT&R
Image shown is a representation only
Manufacturer
Manufacturer No
ICPLW137SMT&R
Package
8-SMD, Gull Wing
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
OPTOISOLTR 5KV OPEN COLL 8-SMD
Detailed Description
Logic Output Optoisolator 10Mbps Open Collector, Schottky Clamped 5000Vrms 1 Channel 10kV/µs CMTI 8-SMD
DataSheet
Data Rate
10Mbps
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Input Type
DC
Output Type
Open Collector, Schottky Clamped
Part Status
Active
Manufacturer
Isocom Components 2004 LTD
Mounting Type
Surface Mount
Package / Case
8-SMD, Gull Wing
Voltage - Supply
7V
Number of Channels
1
Base Product Number
ICPLW137
Voltage - Isolation
5000Vrms
Operating Temperature
-40°C ~ 105°C
Inputs - Side 1/Side 2
1/0
Rise / Fall Time (Typ)
23ns, 10ns
Supplier Device Package
8-SMD
Current - Output / Channel
50 mA
Voltage - Forward (Vf) (Typ)
1.38V
Current - DC Forward (If) (Max)
20mA
Propagation Delay tpLH / tpHL (Max)
100ns, 100ns
Common Mode Transient Immunity (Min)
10kV/µs
| Attribute | Value |
|---|---|
| Data Rate | 10Mbps |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Input Type | DC |
| Output Type | Open Collector, Schottky Clamped |
| Part Status | Active |
| Manufacturer | Isocom Components 2004 LTD |
| Mounting Type | Surface Mount |
| Package / Case | 8-SMD, Gull Wing |
| Voltage - Supply | 7V |
| Number of Channels | 1 |
| Base Product Number | ICPLW137 |
| Voltage - Isolation | 5000Vrms |
| Operating Temperature | -40°C ~ 105°C |
| Inputs - Side 1/Side 2 | 1/0 |
| Rise / Fall Time (Typ) | 23ns, 10ns |
| Supplier Device Package | 8-SMD |
| Current - Output / Channel | 50 mA |
| Voltage - Forward (Vf) (Typ) | 1.38V |
| Current - DC Forward (If) (Max) | 20mA |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Common Mode Transient Immunity (Min) | 10kV/µs |
