Step1: Product
Intersil ISL23345TFRZ
Image shown is a representation only
Manufacturer
Manufacturer No
ISL23345TFRZ
Package
20-VFQFN Exposed Pad
Packaging
Bulk
Description
IC DIG POT 100K 20-QFN
Detailed Description
Digital Potentiometer 100k Ohm 4 Circuit 256 Taps I2C Interface 20-QFN (3x4)
DataSheet
Taper
Linear
Features
Selectable Address
Interface
I2C
Packaging
Bulk
Tolerance
±20%
Memory Type
Volatile
Part Status
Active
Manufacturer
Intersil
Configuration
Potentiometer
Mounting Type
Surface Mount
Number of Taps
256
Package / Case
20-VFQFN Exposed Pad
Voltage - Supply
1.2V, 1.7V ~ 5.5V
Resistance (Ohms)
100k
Number of Circuits
4
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 125°C
Supplier Device Package
20-QFN (3x4)
Temperature Coefficient (Typ)
45ppm/°C
Resistance - Wiper (Ohms) (Typ)
70
| Attribute | Value |
|---|---|
| Taper | Linear |
| Features | Selectable Address |
| Interface | I2C |
| Packaging | Bulk |
| Tolerance | ±20% |
| Memory Type | Volatile |
| Part Status | Active |
| Manufacturer | Intersil |
| Configuration | Potentiometer |
| Mounting Type | Surface Mount |
| Number of Taps | 256 |
| Package / Case | 20-VFQFN Exposed Pad |
| Voltage - Supply | 1.2V, 1.7V ~ 5.5V |
| Resistance (Ohms) | 100k |
| Number of Circuits | 4 |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 125°C |
| Supplier Device Package | 20-QFN (3x4) |
| Temperature Coefficient (Typ) | 45ppm/°C |
| Resistance - Wiper (Ohms) (Typ) | 70 |
