Step1: Product
International Rectifier IRFH7440TRPBF
Image shown is a representation only
Manufacturer
Manufacturer No
IRFH7440TRPBF
Quantity
9171
Availability
In Stock
Package
8-PowerTDFN
Packaging
Bulk
Description
IRFH7440 - 12V-300V N-CHANNEL PO
Detailed Description
N-Channel 40 V 85A (Tc) 104W (Tc) Surface Mount 8-PQFN (5x6)
DataSheet
Mfr
International Rectifier
Series
HEXFET®, StrongIRFET™
FET Type
N-Channel
Packaging
Bulk
Vgs (Max)
±20V
Technology
MOSFET (Metal Oxide)
Part Status
Active
Mounting Type
Surface Mount
Package / Case
8-PowerTDFN
Vgs(th) (Max) @ Id
3.9V @ 100µA
Base Product Number
IRFH7440
Operating Temperature
-55°C ~ 150°C (TJ)
Rds On (Max) @ Id, Vgs
2.4mOhm @ 50A, 10V
Power Dissipation (Max)
104W (Tc)
Supplier Device Package
8-PQFN (5x6)
Gate Charge (Qg) (Max) @ Vgs
138 nC @ 10 V
Drain to Source Voltage (Vdss)
40 V
Input Capacitance (Ciss) (Max) @ Vds
4574 pF @ 25 V
Drive Voltage (Max Rds On, Min Rds On)
6V, 10V
Current - Continuous Drain (Id) @ 25°C
85A (Tc)
| Attribute | Value |
|---|---|
| Mfr | International Rectifier |
| Series | HEXFET®, StrongIRFET™ |
| FET Type | N-Channel |
| Packaging | Bulk |
| Vgs (Max) | ±20V |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Mounting Type | Surface Mount |
| Package / Case | 8-PowerTDFN |
| Vgs(th) (Max) @ Id | 3.9V @ 100µA |
| Base Product Number | IRFH7440 |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Rds On (Max) @ Id, Vgs | 2.4mOhm @ 50A, 10V |
| Power Dissipation (Max) | 104W (Tc) |
| Supplier Device Package | 8-PQFN (5x6) |
| Gate Charge (Qg) (Max) @ Vgs | 138 nC @ 10 V |
| Drain to Source Voltage (Vdss) | 40 V |
| Input Capacitance (Ciss) (Max) @ Vds | 4574 pF @ 25 V |
| Drive Voltage (Max Rds On, Min Rds On) | 6V, 10V |
| Current - Continuous Drain (Id) @ 25°C | 85A (Tc) |
