Infineon Technologies IRS2005STRPBF
Image shown is a representation only
Manufacturer
Manufacturer No
IRS2005STRPBF
Quantity
22253
Availability
In Stock
Package
8-SOIC (0.154", 3.90mm Width)
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
IC GATE DRVR HALF-BRIDGE 8SOIC
Detailed Description
Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
DataSheet
Gate Type
IGBT, MOSFET (N-Channel)
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Input Type
Non-Inverting
Part Status
Active
Channel Type
Independent
Manufacturer
Infineon Technologies
Mounting Type
Surface Mount
Package / Case
8-SOIC (0.154", 3.90mm Width)
Voltage - Supply
10V ~ 20V
Number of Drivers
2
Base Product Number
IRS2005
DigiKey Programmable
Not Verified
Driven Configuration
Half-Bridge
Operating Temperature
-40°C ~ 150°C (TJ)
Rise / Fall Time (Typ)
70ns, 30ns
Supplier Device Package
8-SOIC
Logic Voltage - VIL, VIH
0.8V, 2.5V
High Side Voltage - Max (Bootstrap)
200 V
Current - Peak Output (Source, Sink)
290mA, 600mA
| Attribute | Value |
|---|---|
| Gate Type | IGBT, MOSFET (N-Channel) |
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Input Type | Non-Inverting |
| Part Status | Active |
| Channel Type | Independent |
| Manufacturer | Infineon Technologies |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Voltage - Supply | 10V ~ 20V |
| Number of Drivers | 2 |
| Base Product Number | IRS2005 |
| DigiKey Programmable | Not Verified |
| Driven Configuration | Half-Bridge |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Rise / Fall Time (Typ) | 70ns, 30ns |
| Supplier Device Package | 8-SOIC |
| Logic Voltage - VIL, VIH | 0.8V, 2.5V |
| High Side Voltage - Max (Bootstrap) | 200 V |
| Current - Peak Output (Source, Sink) | 290mA, 600mA |
