Infineon Technologies FP100R12N2T7BPSA2
Image shown is a representation only
Manufacturer
Manufacturer No
FP100R12N2T7BPSA2
Quantity
5
Availability
In Stock
Package
Module
Packaging
Tray
Description
IGBT MOD 1200V 100A AG-ECONO2B
Detailed Description
IGBT Module Trench Field Stop Three Phase Inverter 1200 V 100 A Chassis Mount AG-ECONO2B
DataSheet
Input
Three Phase Bridge Rectifier
IGBT Type
Trench Field Stop
Packaging
Tray
Part Status
Active
Manufacturer
Infineon Technologies
Configuration
Three Phase Inverter
Mounting Type
Chassis Mount
NTC Thermistor
Yes
Package / Case
Module
Base Product Number
FP100R12
Operating Temperature
-40°C ~ 175°C (TJ)
Supplier Device Package
AG-ECONO2B
Vce(on) (Max) @ Vge, Ic
1.5V @ 15V, 100A
Current - Collector (Ic) (Max)
100 A
Input Capacitance (Cies) @ Vce
21.7 nF @ 25 V
Current - Collector Cutoff (Max)
10 µA
Voltage - Collector Emitter Breakdown (Max)
1200 V
| Attribute | Value |
|---|---|
| Input | Three Phase Bridge Rectifier |
| IGBT Type | Trench Field Stop |
| Packaging | Tray |
| Part Status | Active |
| Manufacturer | Infineon Technologies |
| Configuration | Three Phase Inverter |
| Mounting Type | Chassis Mount |
| NTC Thermistor | Yes |
| Package / Case | Module |
| Base Product Number | FP100R12 |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Supplier Device Package | AG-ECONO2B |
| Vce(on) (Max) @ Vge, Ic | 1.5V @ 15V, 100A |
| Current - Collector (Ic) (Max) | 100 A |
| Input Capacitance (Cies) @ Vce | 21.7 nF @ 25 V |
| Current - Collector Cutoff (Max) | 10 µA |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
