Step1: Product
Hammond Manufacturing 1750Z
Image shown is a representation only
Manufacturer
Manufacturer No
1750Z
Packaging
Bulk
Description
AUDIO XFMR 10K / 8 CHAS MNT
Detailed Description
10k Impedance Primary Ohms 8 Impedance Secondary Ohms Audio Transformer 70Hz ~ 15kHz Chassis Mount
DataSheet
Series
175
Packaging
Bulk
Part Status
Active
Power Level
20W
Manufacturer
Hammond Manufacturing
Mounting Type
Chassis Mount
Frequency Range
70Hz ~ 15kHz
Size / Dimension
3.125" L x 2.400" W (79.38mm x 60.96mm)
Transformer Type
Push-Pull Audiophile, Ultra-Linear - Tube Output
Termination Style
Wire Leads
Frequency Response
-1dB
Voltage - Isolation
2000V
Height - Seated (Max)
2.308" (58.62mm)
Operating Temperature
-40°C ~ 105°C
Impedance - Primary (Ohms)
10k
Impedance - Secondary (Ohms)
8
DC Resistance (DCR) - Primary
608.7Ohm, 651.5Ohm
DC Resistance (DCR) - Secondary
706mOhm
| Attribute | Value |
|---|---|
| Series | 175 |
| Packaging | Bulk |
| Part Status | Active |
| Power Level | 20W |
| Manufacturer | Hammond Manufacturing |
| Mounting Type | Chassis Mount |
| Frequency Range | 70Hz ~ 15kHz |
| Size / Dimension | 3.125" L x 2.400" W (79.38mm x 60.96mm) |
| Transformer Type | Push-Pull Audiophile, Ultra-Linear - Tube Output |
| Termination Style | Wire Leads |
| Frequency Response | -1dB |
| Voltage - Isolation | 2000V |
| Height - Seated (Max) | 2.308" (58.62mm) |
| Operating Temperature | -40°C ~ 105°C |
| Impedance - Primary (Ohms) | 10k |
| Impedance - Secondary (Ohms) | 8 |
| DC Resistance (DCR) - Primary | 608.7Ohm, 651.5Ohm |
| DC Resistance (DCR) - Secondary | 706mOhm |
