Step1: Product
Good-Ark Semiconductor SSF2145CH6
Image shown is a representation only
Manufacturer
Manufacturer No
SSF2145CH6
Package
SOT-23-6 Thin, TSOT-23-6
Packaging
Tape & Reel (TR); Cut Tape (CT);
Description
MOSFET 20V 4.8A 6TSOP
Detailed Description
Mosfet Array 20V 4.8A (Tc), 2.9A (Tc) 1.7W Surface Mount 6-TSOP
DataSheet
Packaging
Tape & Reel (TR); Cut Tape (CT); Digi-Reel®
Technology
MOSFET (Metal Oxide)
Part Status
Active
Power - Max
1.7W
Manufacturer
Good-Ark Semiconductor
Mounting Type
Surface Mount
Package / Case
SOT-23-6 Thin, TSOT-23-6
Vgs(th) (Max) @ Id
1V @ 250µA
Operating Temperature
-55°C ~ 150°C
Rds On (Max) @ Id, Vgs
55mOhm @ 3.6A, 4.5V, 80mOhm @ 3A, 4.5V
Supplier Device Package
6-TSOP
Drain to Source Voltage (Vdss)
20V
Input Capacitance (Ciss) (Max) @ Vds
420pF @ 10V
Current - Continuous Drain (Id) @ 25°C
4.8A (Tc), 2.9A (Tc)
| Attribute | Value |
|---|---|
| Packaging | Tape & Reel (TR); Cut Tape (CT); Digi-Reel® |
| Technology | MOSFET (Metal Oxide) |
| Part Status | Active |
| Power - Max | 1.7W |
| Manufacturer | Good-Ark Semiconductor |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Vgs(th) (Max) @ Id | 1V @ 250µA |
| Operating Temperature | -55°C ~ 150°C |
| Rds On (Max) @ Id, Vgs | 55mOhm @ 3.6A, 4.5V, 80mOhm @ 3A, 4.5V |
| Supplier Device Package | 6-TSOP |
| Drain to Source Voltage (Vdss) | 20V |
| Input Capacitance (Ciss) (Max) @ Vds | 420pF @ 10V |
| Current - Continuous Drain (Id) @ 25°C | 4.8A (Tc), 2.9A (Tc) |
