Step1: Product
FSP Technology Inc. FSP120-FZAE1(340)MG
Image shown is a representation only
Manufacturer
Manufacturer No
FSP120-FZAE1(340)MG
Packaging
Box
Description
LED DRIVER CC+CV AC/DC 18-36V 34
Detailed Description
3.4A 18 ~ 36V Constant Current LED Driver AC DC Converter Topology 1 Output
DataSheet
Type
Constant Current
Series
SAE1 (120W)
Dimming
Analog, PWM
Ratings
IP65, IP67
Features
OTP, OVP, SCP
Topology
AC DC Converter
Packaging
Box
Efficiency
93.5%
Part Status
Obsolete
Manufacturer
FSP Technology Inc.
Mounting Type
Chassis Mount
Power (Watts)
120 W
Approval Agency
CE, cULus
Size / Dimension
7.68" L x 2.68" W x 1.53" H (195.0mm x 68.0mm x 38.8mm)
Voltage - Output
18 ~ 36V
Number of Outputs
1
Termination Style
Wire Leads
Base Product Number
FSP120
Voltage - Isolation
500 V
DigiKey Programmable
Not Verified
Operating Temperature
-40°C ~ 70°C (With Derating)
Voltage - Input (Max)
305VAC
Voltage - Input (Min)
90VAC
Current - Output (Max)
3.4A
| Attribute | Value |
|---|---|
| Type | Constant Current |
| Series | SAE1 (120W) |
| Dimming | Analog, PWM |
| Ratings | IP65, IP67 |
| Features | OTP, OVP, SCP |
| Topology | AC DC Converter |
| Packaging | Box |
| Efficiency | 93.5% |
| Part Status | Obsolete |
| Manufacturer | FSP Technology Inc. |
| Mounting Type | Chassis Mount |
| Power (Watts) | 120 W |
| Approval Agency | CE, cULus |
| Size / Dimension | 7.68" L x 2.68" W x 1.53" H (195.0mm x 68.0mm x 38.8mm) |
| Voltage - Output | 18 ~ 36V |
| Number of Outputs | 1 |
| Termination Style | Wire Leads |
| Base Product Number | FSP120 |
| Voltage - Isolation | 500 V |
| DigiKey Programmable | Not Verified |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Voltage - Input (Max) | 305VAC |
| Voltage - Input (Min) | 90VAC |
| Current - Output (Max) | 3.4A |
