Step1: Product
Freescale Semiconductor MC10XSC425EK
Image shown is a representation only
Manufacturer
Manufacturer No
MC10XSC425EK
Package
32-SSOP (0.295", 7.50mm Width) Exposed Pad
Packaging
Bulk
Description
BUFFER/INVERTER BASED PERIPHERAL
Detailed Description
Power Switch/Driver 1:1 N-Channel 6A 32-HSOP
DataSheet
Mfr
Freescale Semiconductor
Series
*
Features
Slew Rate Controlled, Watchdog Timer
Interface
SPI
Packaging
Bulk
Output Type
N-Channel
Part Status
Active
Switch Type
General Purpose
Rds On (Typ)
10mOhm (Max), 25mOhm (Max)
Mounting Type
Surface Mount
Package / Case
32-SSOP (0.295", 7.50mm Width) Exposed Pad
Voltage - Load
6V ~ 20V
Fault Protection
Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO
Number of Outputs
4
Base Product Number
MC10XSC425
Output Configuration
High Side
Ratio - Input:Output
1:1
Operating Temperature
-40°C ~ 125°C (TA)
Current - Output (Max)
6A
Supplier Device Package
32-HSOP
Voltage - Supply (Vcc/Vdd)
3V ~ 5.5V
| Attribute | Value |
|---|---|
| Mfr | Freescale Semiconductor |
| Series | * |
| Features | Slew Rate Controlled, Watchdog Timer |
| Interface | SPI |
| Packaging | Bulk |
| Output Type | N-Channel |
| Part Status | Active |
| Switch Type | General Purpose |
| Rds On (Typ) | 10mOhm (Max), 25mOhm (Max) |
| Mounting Type | Surface Mount |
| Package / Case | 32-SSOP (0.295", 7.50mm Width) Exposed Pad |
| Voltage - Load | 6V ~ 20V |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, UVLO |
| Number of Outputs | 4 |
| Base Product Number | MC10XSC425 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Current - Output (Max) | 6A |
| Supplier Device Package | 32-HSOP |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
