Step1: Product
Freescale Semiconductor - NXP MC10XSD200FK
Image shown is a representation only
Manufacturer
Manufacturer No
MC10XSD200FK
Package
23-PowerQFN
Packaging
Bulk
Description
HIGH-SIDE SWITCH, 36V, DUAL 10MO
Detailed Description
Power Switch/Driver 1:1 N-Channel 6A 23-PQFN (12x12)
DataSheet
Mfr
Freescale Semiconductor - NXP
Features
Internal PWM, Slew Rate Controlled, Watchdog Timer
Interface
SPI
Packaging
Bulk
Input Type
Non-Inverting
Output Type
N-Channel
Part Status
Obsolete
Switch Type
General Purpose
Rds On (Typ)
10mOhm
Mounting Type
Surface Mount
Package / Case
23-PowerQFN
Voltage - Load
8V ~ 36V
Fault Protection
Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Number of Outputs
2
Base Product Number
MC10XSD200
Output Configuration
High Side
Ratio - Input:Output
1:1
Operating Temperature
-40°C ~ 150°C (TJ)
Current - Output (Max)
6A
Supplier Device Package
23-PQFN (12x12)
Voltage - Supply (Vcc/Vdd)
3V ~ 5.5V
| Attribute | Value |
|---|---|
| Mfr | Freescale Semiconductor - NXP |
| Features | Internal PWM, Slew Rate Controlled, Watchdog Timer |
| Interface | SPI |
| Packaging | Bulk |
| Input Type | Non-Inverting |
| Output Type | N-Channel |
| Part Status | Obsolete |
| Switch Type | General Purpose |
| Rds On (Typ) | 10mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 23-PowerQFN |
| Voltage - Load | 8V ~ 36V |
| Fault Protection | Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage |
| Number of Outputs | 2 |
| Base Product Number | MC10XSD200 |
| Output Configuration | High Side |
| Ratio - Input:Output | 1:1 |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Current - Output (Max) | 6A |
| Supplier Device Package | 23-PQFN (12x12) |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
