Fairchild Semiconductor FOD8333R2
Image shown is a representation only
Manufacturer
Manufacturer No
FOD8333R2
Quantity
284
Availability
In Stock
Package
16-SOIC (0.295", 7.50mm Width)
Packaging
Bulk
Description
INPUT LED DRIVE, 2.5 A OUTPUT CU
Detailed Description
3A Gate Driver Optical Coupling 4243Vrms 1 Channel 16-SO
DataSheet
Mfr
Fairchild Semiconductor
Packaging
Bulk
Technology
Optical Coupling
Part Status
Active
Mounting Type
Surface Mount
Package / Case
16-SOIC (0.295", 7.50mm Width)
Approval Agency
UL
Number of Channels
1
Voltage - Isolation
4243Vrms
Current - Peak Output
3A
Operating Temperature
-40°C ~ 100°C
Rise / Fall Time (Typ)
50ns, 50ns
Supplier Device Package
16-SO
Voltage - Output Supply
3V ~ 15V
Current - Output High, Low
2.5A, 2.5A
Pulse Width Distortion (Max)
100ns
Voltage - Forward (Vf) (Typ)
1.45V
Current - DC Forward (If) (Max)
25 mA
Propagation Delay tpLH / tpHL (Max)
250ns, 250ns
Common Mode Transient Immunity (Min)
35kV/µs
